Jan Veenhuis trailers set the benchmark in quality and strength since 1938. There is no compromise in the integrity of design or materials used in the construction. Only Veenhuis design and technology provide longevity, lower maintenance, and optimum performance.
Since 1998 Veenhuis trailers have been imported and sold by Sunova Implement Ltd. As the authorized North American Distributor Sunova now assembles and paints the trailers to the same high standard at their manufacturing facility near Lakeside, Ontario, Canada.
Standard Features
Heavy Duty pivoting draw bar which is adjustable along with a HD coupler eye pintle hitch hook up made of special steel with no welds. This is especially developed and produced by Veenhuis, and includes a manual hand pump with a single acting hydraulic jack stand.
Mechanically adjusted draw bar with rubber pillow block suspension for a smoother ride allows for different tractor draw bar heights. (3 different height settings)
Nylon bushings in main axle pivot are easy to replace by unbolting the retainer. A central lubrication bank makes servicing the tandem walking axle easier.
Veenhuis-engineered double beamed tandem walking axle with eccentric placed centre pivot axle allows having 54% total weight on the rear axles and 46% total weight on the front tires. As a result this style of axle will take less power to pull through wet gravel, mud, sand and other difficult field conditions than any design on the market.
STANDARD FEATURES on the Heavy Duty Agricultural Dump Trailers include a dump box floor that is 3/16 in. (5mm) thick with 1/8 in. (3mm) thick profiled steel sidewalls
Bottom plate and the Sidewalls made out of one piece of steel with no welded seams
Both the sub-frame and the box of our dump trailers are steel blasted, so that the two-component paint adheres better
Tapered dump box with a front step ladder
Tandem axle 10 hole wheel hubs
Rear tail lights and grain door
Hydraulic breaks on all wheels
Dump cylinder mounted in a cardanic ring
Standard wheel sizes 550/60 x 22.5 - 12 ply (line profile) tires
Hydraulic tail gate/top hinged
The floor and side walls are each one profiled sheet of steel meaning no welding seams
Single acting manual hand pump and hydraulic jack stand
PTO pumps available (optional)
Technical Specifications (approx. depending on tire options, etc)
Outside Width
w/750/45R26.5 Tires
120 in.
Overall Height (all models)
150 in
Overall Length
JVSK 18000
342 in.
JVSK 20000
372 in.
Agriculture Specifications
Model
Load Capacity
Inside Box Dim. (L x W x H) with 24'/60cm Extensions
STANDARD FEATURES on the JVZK 19000, 21000, 23000 Heavy Duty Construction Models include a dump box floor & sidewalks that are 6mm or 1/4 thick Hardox AR 400 profiled steel material
Jan Veenhuis has very modern hydraulic guillotine shears and angle benders, both with a working width of 8500 mm, which allows for both the bottom plate and the sidewalls to be made out of one piece of steel with no welded seams
Both the sub-frame and the box of our dump trailers are steel blasted to insure adhesion of two-component epoxy paint
Tapered dump box
Rear tail lights
Dump cylinder mounted in a cardanic ring
Hard wood protectors on top of sidewalls
Safety check valve for dump cylinder
Tires Alliance 750/45R26.5 380 16 ply
Hydraulic Brakes on all 4 wheels
Tandem axle 10 Hole wheel hubs
Brake shoes & drums with slack adjusters
Hydraulic tail gate/top hinged
Adjustable in height (3 different settings)
Single acting manual hand pump and hydraulic jack stand
